Proline Kalibrierthermostate
Calibration and adjustment of temperatures from -40 to 300 °C with LAUDA calibration thermostats

Calibration and adjustment of temperatures from -40 to 300°C with LAUDA calibration thermostats

High-performance comprehensive solution for calibration and adjustment. Constant temperature and homogeneity when calibrating and adjusting in the test chamber - that's what LAUDA calibration thermostats provide.

Depending on the desired size, bath opening and usable depth, different types are available to choose from – each having variable testing chambers, as well as a comprehensive range of products and accessories.

On request, the Proline calibration thermostats enable a temperature range of at least -40 to 300 °C. The Command operating unit is easy and intuitive to use and it can be detached so that it can be used as a remote control.

Overview

Benefits and added value

  • Insulated stainless steel bath vessels with handles and drain tap
  • Two different control heads to choose from: Master with LED display or detachable Command operating unit with graphic LCD display
  • Internal Vario pump with 8 selectable output levels
  • PowerAdapt system for optimally adapted max. heating output without influencing the mains power supply

Working range

For maximum temperatures up to 300 ºC, the compact models of the LAUDA Proline PJ 12 and PJ 12 C can be used, which can also be specially operated to -40°C, together with a LAUDA circulation chiller.

Working temperature min.

Working temperature min.

30 °C

Max. working temperature

Max. working temperature

200 °C

Temperature stability

Temperature stability

0.01 ± K

Product lines



Select up to 4 technical parameters that you want to display in the table

Product Min. temperature range Max. working temp Heating output Integrated interfaces Compare product
Proline PJ 12 30 °C 300 °C 3.6 kW No Details
Proline PJ 12 C 30 °C 300 °C 3.6 kW RS 232/485 Details
Proline PJL 12 30 °C 200 °C 3.6 kW No Details
Proline PJL 12 C 30 °C 200 °C 3.6 kW RS 232/485 Details

Device dimensions

220 x 360 x 630 mm

Proline PJL 12 C

Proline PJ 12 C

220 x 360 x 574 mm

Proline PJL 12

Proline PJ 12

Characteristics

Downloads - general product data

Please select which documents you would like to see in which language:

Available documents
Available languages
Device Device category Document type Language Format File size

Proline Calibration thermostats

Special devices Operating instructions
Englisch
PDF 3,91 MB Download document Download document

Ecoline Calibration thermostats

Special devices Operating instructions
Englisch
PDF 3,91 MB Download document Download document

ECO Gold Calibration thermostat

Special devices Operating instructions
Englisch
PDF 3,91 MB Download document Download document

Accessories
