Universa Cooling thermostats

Universa cooling thermostats in the performance classes Universa ECO, Universa PRO and Universa MAX
Cookies must be enabled to activate the embedded video. By activating them, data is transmitted to the respective provider. Further information can be found in our privacy policy.

Energy-efficient cooling systems with inverter technology

Universa cooling thermostats are available in three performance classes. The economical entry-level variant Universa ECO offers 200 W cooling capacity with a working temperature range of -30 to 100 °C (available from Q4/2025). Universa PRO for professional temperature control covers a working temperature range of -45 to 200 °C with a cooling capacity of 0.2 to 0.8 kW. As the high-end solution and most powerful variant, Universa MAX offers up to 1.6 kW cooling capacity with a working temperature range of -90 to 300 °C. For the control heads, bath bases with a filling volume of 4 to 40 liters are available.

The chillers are available as single-stage and cascade versions. Thanks to the interchangeable control head and the combinable heating/cooling base, LAUDA Universa devices can be flexibly adapted to changing requirements and areas of application. The adaptive bath edge ventilation (patented) of LAUDA Universa cooling thermostats prevents icing and condensation, stops water ingress and blocks vapors to protect the electronics. This innovation significantly increases the operational safety and service life of the appliances.

All Universa devices are equipped with USB, Ethernet and Wi-Fi interfaces as standard. The most powerful models use speed-controlled inverter compressors with electronic expansion valves and adjustable fans. This technology increases energy efficiency by up to 78 percent while significantly reducing operating costs. At the same time, it ensures a longer service life, dynamic start-up of the set temperature and quieter operation.

Overview

Benefits and added value

  • Patented, adaptive bath edge ventilation prevents icing and condensation
  • Adjustment of the flow distribution for internal/external circulation from the front, even during operation (PRO and MAX variants)
  • Natural refrigerant and minimum charge of less than 100 g
  • Integrated web server for wireless remote control and IOT connection for cloud-based data analysis and remote maintenance

Working range

The Universa PRO and Universa MAX cooling thermostats are equipped with a bath cover and pump connections as standard. A drain valve on the front of the device behind the ventilation grid makes it easier to change the temperature control fluid safely.

Min. working temperature

Min. working temperature

-90 °C

Max. working temperature

Max. working temperature

200 °C

Temperature stability

Temperature stability

0.01 ± K

Product lines

Select up to 4 technical parameters that you want to display in the table

ProductMin. working tempMax. working tempHeater power max.Cooling output at 20 °C 50 HzCompare product
Universa U 420 P
Refrigeration technology with natural refrigerants - Icon
-20 °C 200 °C 2.8 kW 0.2 kW Details
Universa U 630 P
Refrigeration technology with natural refrigerants - Icon
-30 °C 200 °C 2.8 kW 0.3 kW Details
Universa U 635 P
Refrigeration technology with natural refrigerants - Icon
-35 °C 200 °C 2.8 kW 0.5 kW Details
Universa U 845 M
Refrigeration technology with natural refrigerants - Icon
-45 °C 200 °C 3.7 kW 0.8 kW Details
Universa U 855 M
Refrigeration technology with natural refrigerants - Icon
-55 °C 200 °C 3.7 kW 1.6 kW Details
Universa U 890 M
Refrigeration technology with natural refrigerants - Icon
-90 °C 200 °C 3.7 kW 0.8 kW Details
Universa U 1245 P
Refrigeration technology with natural refrigerants - Icon
-45 °C 200 °C 2.8 kW 0.8 kW Details
Universa U 1635 P
Refrigeration technology with natural refrigerants - Icon
-35 °C 200 °C 2.8 kW 0.5 kW Details
Universa U 1645 M
Refrigeration technology with natural refrigerants - Icon
-45 °C 200 °C 3.7 kW 1.6 kW Details
Universa U 2040 M
Refrigeration technology with natural refrigerants - Icon
-40 °C 200 °C 3.7 kW 0.8 kW Details
Universa U 4230 M
Refrigeration technology with natural refrigerants - Icon
-30 °C 200 °C 3.7 kW 0.8 kW Details

Device dimensions

350 x 540 x 927 mm

Universa U 2040 M

525 x 615 x 787 mm

Universa U 890 M

310 x 490 x 757 mm

Universa U 855 M

Universa U 845 M

310 x 610 x 757 mm

Universa U 1645 M

310 x 510 x 736 mm

Universa U 1245 P

290 x 480 x 646 mm

Universa U 635 P

210 x 410 x 616 mm

Universa U 420 P

310 x 610 x 736 mm

Universa U 1635 P

450 x 690 x 927 mm

Universa U 4230 M

215 x 460 x 616 mm

Universa U 630 P

Characteristics

Downloads - general product data

Please select which documents you would like to see in which language:

Available documents
Available languages
DeviceDevice categoryDocument typeLanguageFormatFile size
Universa Standard rail Accessories Operating instruction
English
PDF 164,17 kB Download document Download document
Configuration WLAN Universa
(pskCfg.txt)
- Installation manual
English
TXT 237 B Download document Download document
Universa MAX/PRO Immersion thermostats Operating instruction
English
PDF 12,49 MB Download document Download document
Universa MAX/PRO Bath thermostats Operating instruction
English
PDF 12,49 MB Download document Download document
Universa Standard rails Accessories Operating instruction
English
PDF 164,17 kB Download document Download document
