ECO product line

Economical temperature control from -50 to 200 °C

ECO product line

The ECO line includes heating, low-temperature, and calibration thermostats that are appropriate for numerous applications. They are available in Silver (LCD) or Gold (color TFT display) models with a large number of interface modules as accessories. The circulation pump can be adjusted on six levels. The low-temperature thermostats are equipped by default for operation with natural refrigerants.
Inquire about product line

Economical temperature control from -50 to 200 °C

Overview of all ECO devices

ECO Immersion thermostats

ECO Immersion thermostats

LAUDA ECO immersion thermostats in the versions Gold and Silver

Heating output from 1 kW to 2.6 kW

-100
-50
0
50
100
150
200
250
300
20 to 200 °C

ECO Immersion thermostats
ECO Calibration thermostats

ECO Calibration thermostats

Calibration and adjustment of temperatures from -25 to 200 °C with LAUDA calibration thermostats

Cooling output 0.3 kW

Heating output from 1 kW to 2.6 kW

-100
-50
0
50
100
150
200
250
300
-25 to 200 °C

ECO Calibration thermostats
ECO Cooling thermostats

ECO Cooling thermostats

From -50 to 200 °C: Cooling thermostats for economic temperature control in the lab

Cooling output from 0.18 kW to 0.7 kW

Heating output from 1 kW to 2.6 kW

-100
-50
0
50
100
150
200
250
300
-50 to 200 °C

ECO Cooling thermostats
ECO Heating thermostats

ECO Heating thermostats

Heating thermostats from 20 to 200 °C for economic temperature control thermostating in the lab

Heating output from 1 kW to 2.6 kW

-100
-50
0
50
100
150
200
250
300
20 to 200 °C

ECO Heating thermostats
ECO Heating thermostats with transparent bath

ECO Heating thermostats with transparent bath

Heating thermostats including transparent bath for clear temperature control in the laboratory

Heating output from 1 kW to 2.6 kW

-100
-50
0
50
100
150
200
250
300
20 to 100 °C

ECO Heating thermostats with transparent bath

DO YOU NEED ADDITIONAL INFORMATION OR DO YOU HAVE QUESTIONS?


International Area Sales

+49 9343 503-555
E-Mail

Overview of all device types

Select the desired category, working temperature or type of heat dissipation to narrow down the list

Application type

Category

Working temperature (°C)

Heat discharge
Product Min. working temp Max. working temp Heater power max. Cooling output at 20 °C 50 Hz Min. / max. bath volume Compare product
ECO E 4 G 20 °C 200 °C 2.6 kW 3.0 / 3.5 L
ECO E 4 S 20 °C 200 °C 2 kW 3.0 / 3.5 L
ECO E 10 G 20 °C 200 °C 2.6 kW 7.5 / 11.0 L
ECO E 10 S 20 °C 200 °C 2 kW 7.5 / 11.0 L
ECO E 20 G 20 °C 200 °C 2.6 kW 13.0 / 19.0 L
ECO E 20 S 20 °C 200 °C 2 kW 13.0 / 19.0 L
ECO E 25 G 20 °C 200 °C 2.6 kW 16.0 / 25.0 L
ECO E 25 S 20 °C 200 °C 2 kW 16.0 / 25.0 L
ECO E 40 G 20 °C 200 °C 2.6 kW 32.0 / 40.0 L
ECO E 40 S 20 °C 200 °C 2 kW 32.0 / 40.0 L
ECO ET 6 G 20 °C 100 °C 2.6 kW 5.0 / 6.0 L
ECO ET 6 S 20 °C 100 °C 2 kW 5.0 / 6.0 L
ECO ET 12 G 20 °C 100 °C 2.6 kW 9.5 / 12.0 L
ECO ET 12 S 20 °C 100 °C 2 kW 9.5 / 12.0 L
ECO ET 15 G 20 °C 100 °C 2.6 kW 13.5 / 15.0 L
ECO ET 15 S 20 °C 100 °C 2 kW 13.5 / 15.0 L
ECO ET 20 G 20 °C 100 °C 2.6 kW 15.0 / 20.0 L
ECO ET 20 S 20 °C 100 °C 2 kW 15.0 / 20.0 L
ECO GOLD 20 °C 200 °C 2.6 kW
ECO RE 415 G -15 °C 200 °C 2.6 kW 0.18 kW 3.3 / 4.0 L
ECO RE 415 GW -15 °C 200 °C 2.6 kW 0.18 kW 3.3 / 4.0 L
ECO RE 415 S -15 °C 200 °C 2 kW 0.18 kW 3.3 / 4.0 L
ECO RE 415 SW -15 °C 200 °C 2 kW 0.18 kW 3.3 / 4.0 L
ECO RE 420 G -20 °C 200 °C 2.6 kW 0.2 kW 3.3 / 4.0 L
ECO RE 420 S -20 °C 200 °C 2 kW 0.2 kW 3.3 / 4.0 L
ECO RE 630 G -30 °C 200 °C 2.6 kW 0.3 kW 4.6 / 5.7 L
ECO RE 630 S -30 °C 200 °C 2 kW 0.3 kW 4.6 / 5.7 L
ECO RE 1050 G -50 °C 200 °C 2.6 kW 0.7 kW 8.0 / 10.0 L
ECO RE 1050 S -50 °C 200 °C 2 kW 0.7 kW 8.0 / 10.0 L
ECO RE 1225 G -25 °C 200 °C 2.6 kW 0.3 kW 9.3 / 12.0 L
ECO RE 1225 S -25 °C 200 °C 2 kW 0.3 kW 9.3 / 12.0 L
ECO RE 2025 G -25 °C 200 °C 2.6 kW 0.3 kW 14.0 / 20.0 L
ECO RE 2025 S -25 °C 200 °C 2 kW 0.3 kW 14.0 / 20.0 L
ECO REJ 1225 G -25 °C 200 °C 2.6 kW 0.3 kW 9.3 / 12.0 L
ECO SILVER 20 °C 200 °C 2 kW
