The new Ultratemp process thermostats round off the LAUDA portfolio in the upper performance range of biotech and industrial applications. The Ultratemp portfolio includes three models of constant temperature equipment with high heating and cooling capacities, especially for bioreactor applications with reactor volumes from 2000 to 5000 liters. For volumes over 5000 liters, LAUDA Plant Engineering offers even more powerful, customer-specific temperature control systems.
Intuitive operation is provided directly at the device via function buttons and an LCD. Furthermore, the devices can be controlled via PC with an integrated web server. The devices are prepared for the cloud-based digital applications from LAUDA. These offer intelligent analysis and monitoring tools, as well as remote maintenance functions that maximize the operating time, reliability and performance of all LAUDA devices.
LAUDA Ultratemp process thermostats are available with protection level IP 54 as standard. The high-quality stainless steel housing is protected against splash water and allows for easy cleaning of the surfaces.
LAUDA Ultratemp process thermostats enable exact regulation to an external temperature within a range of −5 to 60 °C. Their high temperature stability of ±0.5 K guarantees a precise temperature in the application. The water-cooled design minimizes the heat emitted to the environment. Use with the non-flammable liquids water or water-glycol provides easy handling and low operating costs.
Min. working temperature
-5 °C
Max. working temperature
60 °C
Temperature stability
0.5 ± K
Select up to 4 technical parameters that you want to display in the table
| Product | Min. working temp | Max. working temp | Heater power max. | Integrated interfaces | Compare product | |
|---|---|---|---|---|---|---|
| Ultratemp UT 2505 W | -5 °C | 60 °C | 35 kW | Details | ||
| Ultratemp UT 3505 W | -5 °C | 60 °C | 35 kW | Details | ||
| Ultratemp UT 5005 W | -5 °C | 60 °C | 50 kW | Details |
| Device | Device category | Document type | Language | Format | File size | |
|---|---|---|---|---|---|---|
| Ultratemp | Process thermostats | Brochure |
English
| 1,39 MB |
Download document
| |
| Ultratemp | Process thermostats | Operating instruction |
English
| 1,53 MB |
Download document
|
