Two lead-throughs with an internal diameter of 13 mm as standard, for inserting control sensors, eg Type Pt100
Limit values for high and low temperature alarm adjustable
Display and alarm functions are maintained in the event of a power failure (battery backup)
Built-in data logger for storing temperature and alarm data
Cooling coils blown into the sides ensure direct cold transfer from all sides, high freezing speed and uniform temperature distribution throughout the whole cabinet
Vacuum insulation means more storage space with a reduced footprint
Magnetic sealing system reliably prevents the door / lid seals from freezing on
工作范围
最小工作温度
-40 °C
最大工作温度
0 °C
Technical data
工作温度范围
-40 ... 0 °C
温度稳定性
3 ± K
环境温度范围
15 ... 28 °C
有效空间
205 L
有效空间尺寸(宽x深x高)
790 x 520 x 500 mm
尺寸(宽x深x高)
960 x 790 x 1130 mm
重量
188 kg
冷却时间
从 20 °C 到 -40 °C 在 3 h
解冻时间
从 -40 °C 到 0 °C 在 6 h
电源供应
115 V; 60 Hz
电源插头
带插头的电源线 (NEMA 5-15P)
Certification
NRTL 根据 UL 61010-1:2012/R:2019-07, CSA C22.2 No. 61010-1:2012/A1:2018-11, CSA C22.2 No. 61010-2-011:2019, UL 61010-2-011:2021
