Water baths from 25 to 100 °C for the lab

The water baths of the LAUDA Hydro series are optimally equipped for every application in the laboratory and ensure homogeneous temperature distribution without local overheating. LAUDA Hydro water baths with precise temperature distribution and optional circulation are designed for the needs of biological, medical or biochemical laboratories.

LAUDA Hydro water baths made of high-quality stainless steel offer the right bath depth and opening for every application with bath volumes from 4 to 41 litres. All water baths offer a temperature range of up to 100 °C with a temperature constancy of ±0.1 K, so that applications in the boiling range are also possible. A TFT colour display ensures intuitive operation with a temperature display in °C and °F.

Working temperature min.

25 °C

Working temperature max.

100 °C

Temperature stability

0.1 ± K

Hydro H 16 A Hydro H 8 A Hydro H 24 Hydro H 22 Hydro H 8 Hydro H 4 Hydro H 41 Hydro H 16
Working temperature range 25 °C to 100 °C 25 °C to 100 °C 25 °C to 100 °C 25 °C to 100 °C 25 °C to 100 °C 25 °C to 100 °C 25 °C to 100 °C 25 °C to 100 °C
Temperature stability 0.1 ± K 0.1 ± K 0.1 ± K 0.1 ± K 0.1 ± K 0.1 ± K 0.1 ± K 0.1 ± K
Heater power max. 1.5 kW 1 kW 1.5 kW 1.5 kW 1 kW 0.5 kW 1.5 kW 1.5 kW
Bath volume min. / max. 7.5 / 13.9 L 3.8 / 7.0 L 11.3 / 20.9 L 7.5 / 20.3 L 3.8 / 7.0 L 1.9 / 3.5 L 9.3 / 37.9 L 7.5 / 13.9 L
Bath opening max. width_Bath opening max. depth 400 mm to 245 mm 245 mm to 200 mm 600 mm to 245 mm 400 mm to 245 mm 245 mm to 200 mm 245 mm to 100 mm 410 mm to 296 mm 400 mm to 245 mm
Bath depth 165 mm 165 mm 165 mm 225 mm 165 mm 165 mm 335 mm 165 mm
Interfaces integrated No No No No No No No No
