Calibration and adjustment of temperatures from -40 to 300 °C with LAUDA calibration thermostats

LAUDA calibration thermostats provide constant temperature and homogeneity in calibration and adjustment in the test chamber. The ideal solution in comparison to heat cabinets and metal block thermostats, since liquid thermostats transfer heat in the temperature control liquid 40 to 60 times better than via air.

For maximum temperatures up to 300 ºC, the compact models of the LAUDA Proline PJ 12 and PJ 12 C can be used, which can also be specially operated to -40°C, together with a LAUDA flow through cooler.

Working temperature min.

-40 °C

Working temperature max.

300 °C

Temperature stability

0.01 ±K

Proline PJL 12 Proline PJL 12 C Proline PJ 12 Proline PJ 12 C
Working temperature min. 30 °C 30 °C 30 °C 30 °C
Working temperature max. 200 °C 200 °C 300 °C 300 °C
Temperature stability 0.01 ±K 0.01 ±K 0.01 ±K 0.01 ±K
Bath volume max. 13.5 L 13.5 L 13.5 L 13.5 L
Bath depth 320 mm 320 mm 320 mm 320 mm
Heater power 3.5 kW 3.5 kW 3.5 kW 3.5 kW
Pump pressure max. 0.8 bar 0.8 bar 0.8 bar 0.8 bar
Pump flow max. (pressure) 25 L/min 25 L/min 25 L/min 25 L/min
Pump flow max. (suction)
Download data sheet
Download brochure
Technical data
Compare product

There are already three products in your comparison list.
To compare other products, please delete one of the products in your comparison list.

Removable remote control unit for easy and intuitive operation
Constant immersion depth thanks to a calibration chamber with overflow principle
